laser engraving machine for metal
| Price: | 188.99 USD |
| Payment Terms: | T/T,Paypal |
| Place of Origin: | Guangdong, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
Single package size: 59X21X12 cm
Single gross weight: 4.000 kg
Package Type: X-axis Aseembly+Y-axis Aseembl
Ortur OEM ODM cnc Craft graveurbois mini making machine laser engraver for ceramic
PRODUCT SPECIFICATIONS
No | Item | Data | ||
1 | LU1-2 | Electric Power 7W, Luminous Power 1200-1600MW | ||
2 | LU1-3 | Electric Power 15W, Luminous Power 4000-4500MW | ||
3 | LU1-4 | Electric Power 20W, Luminous Power 5000-5500MW | ||
4 | Baud Rate | 115200-921600(default 115200) | ||
5 | Available Materials for Engraving | Wood, Paperboard, Acrylic, Leather, Some Plastic, Power Coated Metal, Coated Glass, Stone, Ceramic | ||
6 | Available Materials for Cutting | Kraft Paper, Paper Board, Thin Plywood, KT board, Felt Cloth, Leather, etcs | ||
7 | Computer OS | Win XP, Win7, Win8, Win 10(LaserGRBL) Max and Linux(LightBurn) | ||
8 | Default Focus Length | 58$55mm(from the heat sink to the object) |
Applicable Material:Acrylic, Glass, Leather, MDF, metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, wood
Engraving Area:400*430mm
Laser Type:DIODE
Engraving Speed:0-3,000MM/Min
Graphic Format Supported:NC, DXF, BMP, JPG, PNG, Other Static image.
Condition:New
Place of Origin:Guangdong, China
Brand Name:Ortur
Dimension(L*W*H):570*550*175mm
Certification:ce
Laser Source Brand:China famous brand
Weight (KG):3.5 KG
Key Selling Points:High Safety Level
Warranty:1 Year
After-sales Service Provided:Online support
Applicable Industries:Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Advertising Company
After Warranty Service:Video technical support, Online support, Spare parts
Local Service Location:None
Showroom Location:None
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Marketing Type:New Product 2020
Warranty of core components:1 Year
Core Components:Mainboard, Laser module
Product name:engraver laser
Motherboard:OLM V1.3 Motherboard,with STM32 MCU
Protection:Active Position Protection
Key words:laser engraving machine laser cutter engraver
Function:Laser Beam Safety Guard
Pixel Accuracy:Adjustable (Default: 300 pixels per inch, about 0.81um Pixel Accuracy)
Available Laser Modules:LU1-2, LU1-3, LU1-4
Wave Length:445±5nm
G.W:3.5KG
Features:
●Specialized Motherboard with STM32 MCU
●The Most Advanced 32Bits Laser Engraver Firmware
Ortur laser master firmware, smarter, faster, higher precision and easier to use.
● Laser power range could be S0 - S1000
● Engraving speed could be as high as 3000MM/Min.
●Active Position Protection
●Laser Beam Safety Guard
●Exposure Duration Detection and Limitation
● LaserGRBL ( free software ) supports Windows XP, 7, 8, 10.
● LightBurn (not free software, lightburnsoftware.com ) supports Windows, Mac OS, and Linux. It's the most popular paid carving software in the world, very easy to use.
● This laser engraver supports PWM mode.
● Pre-assembled parts, just need 10 - 20 minutes to install the machine.
● 400 x 430 mm large engraving area.
● Aluminum profile frame + structured cabling, solid structure, smooth operation, attractive appearance
● Synchronizing shaft mechanical structure, avoid out-sync on two Y rails, during full speed engraving.
